EK-Quantum Vector2 EVO Strix-TUF RTX 4090 - Table of Contents

- 3 -
TABLE OF CONTENTS
BOX CONTENTS 4
WATER BLOCK DIMENSIONS 5
TECHNICAL SPECIFICATIONS AND WATER BLOCK PARTS 6
NICKEL PLEXI 6
PREPARING THE GRAPHICS CARD 7
REMOVING THE STOCK COOLER 7
ASUS TUF-STRIX GEFORCE RTX 4090 7
PREPARING THE WATER BLOCK FOR INSTALLATION 9
CUTTING AND PLACING THERMAL PADS - WATER BLOCK 10
APPLYING THERMAL COMPOUND 12
ATTACHING THE WATER BLOCK (Option 1: GeForce RTX 4090 ROG Strix) 13
ATTACHING THE WATER BLOCK (Option 2: GeForce RTX 4090 TUF) 14
CUTTING AND PLACING THERMAL PADS - BACKPLATE 16
ATTACHING THE BACKPLATE 18
INSERTING THE GRAPHICS CARD INTO THE CHASSIS 18
FITTINGS AND TUBING 19
CONNECTING THE D-RGB LED STRIP 19
TESTING THE LOOP 20
WARRANTY 20
SUPPORT AND SERVICE 21
SOCIAL MEDIA 21
