Electronic convection oven rev. 11 ________________MODD. EKF 616 TC – EKF 664 TC – EKF 711 TC – EKF 1016 TC
EKF 1064 TC – EKF 1111 TC – EKF 1664 TC – EKF 2011 TC
_________________________________________________________________________________________ page 19
Glass “down” and door open with tray trolley in
With tray trolley in, the display shows the RED/BLUE SCREEN (flashing) with the words “LIFT
DOOR GLASS“. A sound alarm goes off, which is repeated intermittently. This internal glass
position with the tray trolley in, does not allow the door to be closed. If the trolley hits against the
glass it might break it: injury hazard!
Glass “up” and door open with no tray trolley inserted
The RED SCREEN (warning) is displayed with the words “DOOR GLASS LIFTED”.
Glass “up” and door closed with no tray trolley inserted
The RED/BLUE SCREEN (flashing) is displayed with the words “LOWER DOOR GLASS”. A sound
alarm goes off, which is repeated intermittently. This internal glass position without the tray trolley
in, does not let the oven be used in any way
Glass “up” and door closed with tray trolley inserted
The PARAMETER SCREEN is displayed (cooking cycle parameters to be set) or the OVERVIEW
SCREEN (cooking cycle parameters already set); in both cases the oven may be regularly used for
baking.
Warnings
The ALARMS/WARNINGS screens are visible on the display as soon as a cooking cycle is set.
Adequate heat protection must be worn if the internal glass is moved after completing the “pre-
heating” stage or a cooking cycle, burn hazard!
4.3.2.2 Selection of cooking parameters
The following parameters may be set for each step of the cooking cycle (up to 9 steps):
1. Cooking time
2. Cooking chamber temperature
3. Core temperature
4. Delta T
5. Percentage (%) of humidity/steam activation
To confirm the set parameter and move to the next one, act on the “SELECT” key. The
airflow speed inside the cooking chamber may be modified (3 available speeds) by acting on
key .
Warning
A complete cooking cycle does not obligatorily require all 9 available steps, therefore it is possible
to set only the desired ones without affecting correct oven operation.
4.3.2.3 Cooking time or core temperature settings
Each cooking step is controlled by the cooking time parameter or core temperature parameter.
The time and core temperature parameters are mutually exclusive: if the core temperature
parameter is set, the time parameter is automatically deleted even if it has been previously set.
Warnings
Setting excessively short cooking times or excessively low core temperatures with respect to
correct values may lead to incomplete cooking.
Setting excessively long cooking times or excessively high core temperatures with respect to
correct values may result in excessively dry food, with the risk of burning the surface.
