Section 8 - Page 1 of 2
3121-9001-0167_EN.03.00_QT_Manual 04/2016
Quo-Test Analyzer
Accessories
Section 8 Technical Specifications
ANALYZER
Size 205mm(h) x 205mm(w) x 135mm(d)
Weight 1.3kg
Display
Blue LCD backlit monochrome display 128x64 pixels.
Visible area 70x39mm
Connections USB 2.0 (slave), Printer (RS232), Barcode Scanner (PS2)
Data Memory Capacity 7,000 data records
POWER SUPPLY
Mains Adapter Separate AC to DC mains adapter
Input 100-240 V AC, 50-60 Hz, 30 W
Output 24 V DC, 1.25A
BATTERY
Type
CR1225, Lithium, non-rechargeable / non-replaceable.
Used to maintain the date, time and memory
of the analyzer
BARCODE READER
Barcode
Scanner
T8-W CCD Hand Scanner
Part No. 0108-0035
Width of Field 80 mm
Interface Keyboard PS2
Supported Barcode
Formats
Code 128, Code 39, NW7 / Codabar, 2 of 5 interleaved
To Next Page
