A12 INSTALLATION MANUAL
Appendix A: Specifications
Audio Section
Power Rating - Output Power 12 x 40W RMS @ 8 Ohms
Frequency Response 20Hz to 20kHz, +/-1dB into 8 Ohms
Full Power Bandwidth 5Hz to 55kHz, -3dB into 8 ohms
Signal-To-Noise > 95dB (A-weighted)
Channel Separation >-70dB (Channel to Channel @1kHz)
Total Harmonic Distortion < .01% @ 1kHz
< 0.06% @ 10kHz
Intermodulation Distortion < 0.1%
Voltage Gain (AV) Continuously Variable from 0 - 20
Slew Rate > 9 V/microsecond
Input Impedance 47k Ohms
Input Sensitivity 0.707 mV RMS
Connectors
Input/Loop Outputs Gold RCA Phono
Speaker Outputs Removable Locking Terminals
Power
AC Power Requirements A12-120 VAC, 440 Watts
A12240-240 VAC, 440 Watts
Power Supply Ultra-High Efficiency Toroidal Transformer
Triggers
Remote Trigger Inputs 5 to 24 VDC
Remote Trigger Outputs +12 VDC @0.1A
Dimensions/Weight
Dimensions w/ Feet (2U w/o Feet) 17 W x 4 1/8 H x 14 D (in)
432 W x 105 H x 356 D (mm)
Weight 20 lbs/9.07 kg
