© ELAN Home Systems, Inc. 2004 • All rights reserved. 7/04 Page 17
D1650/D1651 INSTALLATION MANUAL
ELAN HOME SYSTEMS
© ELAN Home Systems, Inc. 2004 • All rights reserved. 7/04 Page 17
4. Troubleshooting
SYMPTOM CAUSE SOLUTION
No Audio From One or More
Channels
1. Loose/Bad peaker Cable S
Connection
Check Cable Ends at Binding
Posts and Speaker Terminals
2. Break/Short in Speaker Cable Check Continuity of Each Speaker
Cable Using Multimeter.
If Short or Open is Indicated, Check
Wiring for Proper Connections.
3. Speaker is defective Swap with Known Good Speaker
4. RCA Patch Cable Defective Swap with Known Good Patch
Cable.
5. Source not Sending Audio Verify Source is Powered Up and
Playing. Check any Tape Monitor
Settings on A/V Receiver.
Channel is in MUTE
Make sure triggering device’s
remote output is connected and
producing voltage.
Amplifier in Protection Mode
Find short or low-impedance
condition. Correct overheating or
AC power issues. Once issue is
found and resolved, cycle power to
D1650. This
condition could be
caused by 1. 2.,3., and/or 4 above.
Audio “Hum”
1.Ground Potential Difference
Between Source Components
(Ground Loop)
Plug All Sources into Same AC
Outlet.
Test AC Outlet Using Ground
Tester.
2. Faulty/Damaged Cables Check Source Equipment Cables
For Damaged Cables and Faulty
Connections.
3. Faulty Wiring Make Sure Any Volume Controls
Are Not Hooked Up Backwards.
Check for Shorts in Wiring
(See item 2 in “No Audio…”)
Distorted Audio at Normal
Volume Levels
1. Input Gain Too High Reduce Gain to the Channel in
Question. Ensure Red Clipping
LEDs are not Pulsing or On
Constantly.
2. Defective/Incompatible
Speaker
Check for Physical Damage to
Speaker
Check Power Ratings on Speaker
Do Not use Speakers Rated for
Less than 50
Watts RMS.
3. Volume Control Miswired Check for Proper Input/Output
connections at Volume Control.
INPUT Comes from Amplifier,
OUTPUT Goes to Speakers.
"MUTED!" Flashes on Display,
Then Volume Setting
"ERROR!" Message Displayed
on Front Panel
To Next Page
