ELAN E4 – Owner's manual
28
Figure 12-2
1. Galley sink outflow
2. Galley sink water seacock
3. Toilet sink outflow
4. Toilet sink water seacock
5. Waste water holding tank – 70 l
6. Holding tank air vent
7. Waste tank dockside suction
8. Toilet sea water inlet seacock
9. Toilet waste water seacock
10. Manual toilet
CAUTION: NEVER use the waste water pump with the outlet seacock closed.
NEVER use any other but thin absorbent toilet paper and never too much.
Follow the instructions for use and precautions marked on the pump.
If the pump breaks down, it will have to be taken apart and cleaned.
The mechanism is maintained by rinsing the whole system with fresh
water. This is done by operating the pump.
NOTE: Observe local regulations on discharge!!!
7.4. BILGE WATER SYSTEM
The bilge strainer is located under the saloon floor. Lifting the boards in front of the
companionway will allow you access to the bilge pump via a bilge strainer.
The boat in version 1 is also equipped with separate bilge pump with floating switch in the
stovage compartment. The manual pump switch is located in stowage compartment near
the fire extinguisher.
