ELAN M86A INSTALLATION MANUAL
© ELAN 2010 | All rights reserved.
Page 35
Audio (Continued)
Symptom Possible Cause Solution
playing on speakers
Source connected to wrong input of
M86A.
1. Verify / correct input connections.
2. Speakers connected to incorrect
speaker outputs.
2. Verify / correct speaker connections.
Video
Symptom Possible Cause Solution
Video not switching
when using V8
Video Router
1. VIANet connection faulty or not
connected.
2. Incorrect programming
3. V8 unit ID not set correctly.
1. Connect Cat5 using VIANet wiring color code. Verify
connections.
2. Verify / correct programming.
3. Set unit ID correctly.
Video switches but
is incorrect
1. Source video not connected to the
correct input.
2. Video Outputs of the switcher
connected to the wrong TS7s /
monitors.
3. V8 unit ID set incorrectly.
1. Connect source video correctly.
2. Connect Video Outputs to the correct TS7s / monitors.
3. Set unit ID correctly.
Sense Input
Symptom Possible Cause Solution
Conditional
commands / Event
Maps not working
properly
1. Conditional programming / Event
Map incorrect
1. Verify / correct programming in the ELAN
configuration software
2. Sensor faulty or not connected
properly
3. Incorrect Sensor being used
4. VIANet connection not made / faulty
2. Verify / correct Sensor operation and connection.
3. Use correct sensor
4. Verify / correct VIANet connection
