ELAN M86A INSTALLATION MANUAL
© ELAN 2010 | All rights reserved.
Page 36
IR/VIANet Control
Symptom Possible Cause Solution
Zone IR receive LED
does NOT flash
when a button is
pressed.
1. IR controller not programmed or
programmed with a non-ELAN
command.
1. Program IR controller or correct programming.
2. IR signal path wiring bad. 2. Verify IR signal path wiring. Check touchpads, IR
sensors, etc.
Intermittent control
from IR controller.
IR flooding. Zone IR receive LED glowing or flickering when no
commands are being sent indicates IR flooding. Possible
sources: ambient light or plasma / LCD TV flooding.
Source IR
commands not
working
1. IR Link not connected between
System Controller and M86A
2. Incorrect Programming
1. Connect DB-15 Male to Female Cable
2. Correct Programming
Source IR
commands only
work from zones on
MAIN chassis
IR Expansion ports not connected
between M86A chassis
Connect DB-15 cables between M86A chassis
VIANet Commands
not working
1. VIANET wiring incorrect. 1. Verify / correct wiring.
2. Chassis unit ID set incorrectly. 2. Set chassis unit ID correctly. (See page 31.)
3.
Incorrect commands
3.
Verify / Correct programming
