Specifications (Continued)
Item Description
Connectors
AC Power
VIA!NET IN/OUT
TS2 Inputs (6)
Zone Speaker Outputs (6)
Source IR Expansion IN/OUT
Zone Pre-Amp Outputs (6)
Music On-Hold (MOH OUT)
Page In/Out (PG IN/OUT)
Source Loop Audio Outputs (8)
Source Audio Inputs (8)
ELAN Sense Inputs (6)
Source IR Outputs (8)
All Zones IR Output
Programming
3-Prong Heavy Duty Cord
RJ-45
RJ-45
Removable Quick Lock Connectors
15-Pin Connection
RCA Type, Line Level Only
RCA Type, Line Level Only
RCA Type, Line Level Only
RCA Type, Line Level Only
RCA Type, Line Level Only
3.5mm Connectors (stereo)
3.5mm Connectors (mono)
3.5mm Connector (stereo)
USB-Mini
General
TS2 Power (Zone Input Connection)
Power Requirements
Power Consumption
300mA @ 12VDC per zone
120VAC 50/60 Hz
(M86A240) 230-240VAC 50/60Hz
400 W
Dimensions w/Feet
2U w/out feet
Weight
Unit Weight
Carton Weight
17”W x 4 1/8” H x 16 5/8” D (432mm W x 105mm H x 422mm D)
26 lbs (11.8 kg)
29 lbs (13.2 kg)
