Elation Professional Scene Setter - Rear View; Power Switch

1. Overview
35. Power Switch
36. DC Input
37. MIDI Thru/Out/In
38. DMX Out
39. DMX Polarity Select
40. Audio Input
41. Remote Input
42. Fog Machine Connector
This switch controls turning on or off of the power.
DC 12-20V, 500 mA Min.
MIDI ports for connection to a sequencer or MIDI device.
or DMX pack.
Used to select DMX polarity.
from 100mV to 1Vpp.
control using a standard 1/4"stereo jack.
Black Out and Full On may be controlled by a remote
This jack accepts a line level audio input signal ranged
This connector sends your DMX value to the DMX fixture
1.2 Rear View
DC INPUT
DC 12V~20V
500mA min.
+
100mV~1Vp-p
AUDIO
LINE INPUT
1/4"stereo jack
Full on
GND
REMOTE
IN
OUT
THRU
MIDI DMX OUT
DMX Polarity Select
1
2
3
1=Ground
2=Data
3=Data +
1=Ground
2=Data +
3=Data
ON OFF
POWER
FOG MACHINE
Stand By
or Black Out
35
36
40 424137 38 39
