Elcometer 224 User Guide

Section
Page
1
Gauge Overview
en-2
2
Box Contents
en-2
3
Using the Gauge
en-3
4
Getting Started
en-4
5
Taking a Reading
en-6
6
Calibrating & Testing the Gauge Calibration
en-7
7
Batching - Model T
en-9
8
Displaying Graphs
en-9
9
Menu Structure - Model B
en-10
10
Menu Structure - Model T
en-11
11
Downloading Data & Upgrading Your Gauge
en-12
12
Technical Specification
en-13
13
Elcometer 224 Separate Probes
en-13
14
Legal Notices & Regulatory Information
en-14
www.elcometer.com
Hg
CONTENTS
Pb
R
en-1
These operation instructions are a short User Guide only. A copy of both this Instruction Manual and an English
language extended version are available for download on our website elcometer.com. For the avoidance of doubt,
please refer to the original English language version.
Gauge Weight: Integral: 218g (7.69oz) including batteries
Separate: 161g (5.68oz) including batteries
Applicable Patents: GB2505193, US9261345
© Elcometer Limited 2012 - 201 . All rights reserved. No part of this document may be reproduced, transmitted, 9
transcribed, stored (in a retrieval system or otherwise) or translated into any language, in any form or by any
means (electronic, mechanical, magnetic, optical, manual or otherwise) without the prior written permission of
Elcometer Limited.
Gauge Dimensions: Integral: 168 x 73 x 37mm (6.61 x 2.87 x 1.46")
Separate: 141 x 73 x 37mm (5.55 x 2.87 x 1.46")
