Elcometer 224 User Guide

1 GAUGE OVERVIEW
www.elcometer.com
en-2
2 BOX CONTENTS
<
Elcometer 224 Surface Profile Gauge
<
Calibration Test Foils; Nominal Values 125 & 500µm and
a
Glass Zero Tile (Integral gauges)
<
a
Probe Protection Cap (Integral gauges)
<
Wrist Harness
<
Protective Case (Model B)
<
Transit Case (Model T)
<
1 x Screen Protector
<
2 x AA Batteries
<
®
USB Cable & ElcoMaster Software (Model T)
<
Test Certificate
<
User Guide
R
1
2
3
4
5
9
7
8
6
2 Colour Screen
4 On/Off Key
7 Wrist Strap Connection
1 LED Indicators -
Red (left), Green (right)
3 Multifunction Softkeys
6 Internal Probe
5 Separate Probe
Connection
8 Battery Compartment
(¼ turn open/close)
9 USB Data Output Socket
(below cover)
a
For separate gauges, the test foils, glass zero tile and probe protection cap are supplied with the
separate probe.
