6 CALIBRATING AND TESTING THE GAUGE CALIBRATION
6.2 CALIBRATING THE GAUGE AFTER PROBE TIP REPLACEMENT
The precision manufactured probe tip will wear after continued use.
This is a consumable item which can be replaced by the user.
Description Part Number
Replacement Probe Tips (x5) T22420095
Replacement Probe Tips (x2) with Fixing Tool T22420053
3 Follow the on-screen instructions.
The calibration can be checked at any time without affecting any
statistics or batch memory by following the procedure below and
comparing the reading value displayed with the glass zero or
measured foil value.
To re-calibrate after tip replacement:
1 Press the Cal softkey.
To test the gauge calibration:
3 When prompted, either place the probe on to the glass zero tile or
on the centre of the foil resting on the glass tile, making sure the
pin goes through the hole in the centre of the foil.
2 Select “Tip Change Calibration” (Model T only).
2 Select “Test Calibration” and follow the on-screen instructions.
1 Press the Cal softkey.
6.3 TESTING THE GAUGE CALIBRATION (MODEL T)
Re-calibration is required after a tip replacement to ensure the
continued accuracy of the gauge.
90°
www.elcometer.com
en-8
