15
gauge and an external surface temperature probe against a ferrous surface. See “Elcometer 319/2
Dewpoint Meter Dock” on page 16 for more information.
5. Scroll to Log and then press OK.
The measurement screen is displayed. If the battery symbol [ ] is blinking, replace the batteries
before continuing - see “Fitting batteries” on page 6.
The Start option at the bottom of the display is highlighted automatically.
6. To start measuring, press OK.
The Start option at the bottom of the display changes to Stop.
The current log record number and interval time are shown at the bottom of the
display.
Each log record contains the following measurements:
Relative humidity, ambient temperature, surface temperature, dewpoint
temperature, Delta-T, and the time and date.
The trend indicator [ ] between the parameter and the reading indicates if
the value is increasing [ ] or decreasing [ ].
A flashing green LED in the corner of the display indicates that logging is in
progress.
7. To stop logging and close the batch, press OK. Note that you cannot resume measuring this batch
once logging has been stopped.
8. Scroll to Yes and then press OK to confirm that you want to stop logging. The data is saved and the
BATCH menu is displayed.
RH 72,0 %
Ts 23,2 C
Ta 24,0
Td 18,6
O
O
O
C
C
Log nr. 0
Int. 10s
