5 TAKING MEASUREMENTS - USING ‘LOG MANUAL’
Follow this procedure to take measurements manually and log the results into your
gauge memory. Each time a measurement is taken, the readings are written into the
batch selected.
1. From MENU, scroll to Log manual and then press OK.
The LOG MANUAL menu is displayed. This menu lists all the batches.
Empty batches [ ] and batches which have been used previously for
manual logging [ ] can be used for manual logging. Closed batches [ ]
cannot be used.
Note: If the gauge memory is full, the batches are unavailable [ ] and the
batches must be cleared before logging can start.
Batches are given numbers by your gauge (Batch 1, Batch 2, etc.). If required,
use ElcoMaster
TM
software (see page 17) to give your batches names instead
of numbers.
Log interval
Setup
22/06/07
12:23
Batch 2
Batch 3
Batch 4
Batch 5
Batch 6
Batch 7
Batch 8
Back
