• Create a user screen and upload it to your gauge (see page 30).
ElcoMaster and ElcoMaster Mobile are on the CD supplied with your gauge and they can also be
downloaded, together with any subsequent upgrades, from the Elcometer website www.elcometer.com
Your gauge is also fully compatible with ElcoShip - see www.elcoship.com for further details.
To use ElcoMaster for data transfer, the software must be installed on your PC and your gauge must be
connected to your PC using Bluetooth or the USB cable.
11.1 INSTALLING ELCOMASTER SOFTWARE
1. Place the CD in your PC.
The software installation wizard should run automatically. If it does not run automatically:
• Click Start > Run
• Type D:AutoCIS (where ‘D’ is the letter of your CD drive)
• Click OK. The software installation wizard will run.
2. Follow the on-screen installation instructions.
Follow the instructions included with ElcoMaster to interface your gauge with your PC.
If at any time ElcoMaster requests a PIN number for your gauge, press Menu>Bluetooth. The Bluetooth PIN is
displayed next to Authentication. Note that each gauge has a unique PIN - use only the PIN for your gauge.
11.2 TRANSFERRING READING DATA USING THE USB CABLE
1. Connect your gauge to your PC using the USB cable.
2. Switch on your gauge and ensure the Reading Screen is displayed.
3. Start ElcoMaster and follow the separate instructions included with ElcoMaster.
