Elcometer 456 User Guide

1 Rotate the probe plug to align the pins
2 Screw in the collar - clockwise
3 GETTING STARTED
www.elcometer.com 4
1 Press and hold the ON/OFF button until the Elcometer logo is displayed
é
2 Select your language using the softkeys
ê
3 Follow the on screen menus
To access the language menu when in a foreign language:
1 Switch the gauge OFF
2 Press and hold the left softkey and switch the gauge ON
é
3 Select your language using the softkeys
ê
4 CONNECTING YOUR PROBE - SEPARATE GAUGES ONLY
en
R
1
2
1
2

Elcometer 456 Specifications

General

Model	Elcometer 456
Category	Coating Thickness Gauge
Power Supply	2 x AA batteries
Interface	USB, Bluetooth
Data Output	USB, Bluetooth
Measurement Principle	Magnetic Induction or Eddy Current (depending on probe)
Substrate	Ferrous or Non-Ferrous (depending on probe)
Units	µm, mils
Operating Temperature	-10°C to 60°C (14°F to 140°F)
Standards	ISO 2178, ISO 2360, ASTM B499, ASTM D7091
Display	LCD
