Operating and Service Instructions for the Electro-Voice 7300A Power Amplifier
1 .
2 .
Verify that the amplifier
is properly connected to
an ac power source and
that the source is active.
Verify that the input
connections are properly
made. Refer to Figure 3.
FAX: (616) 695-1304
Electro-Voice Customer
Service/Repair
8324 Doe Avenue
Visalia, CA 93219 U.S.A.
Tel: (209) 651-7777
FAX: (209) 651-0164
3. Verify that the output
connections are properly
made. Refer to Figure 4.
4. Check the input and
output cables for proper
wiring and continuity.
5. C heck the signal source
and the load.
6. Insure that the two jump¬
ers for each octal socket
are properly installed (if
not using optional plug-in
modules).
7. Insure that any accessory
modules installed do not
draw more than 25 ma
DC of current.
8. Check that the mode
switch is in the desired
position.
NOTICEj Repairs performed by
other than authorized warranty
stations (Dealers) or qualified
personnel shall void the warranty
period of this unit. To avoid loss
of warranty, see your nearest
Electro-Voice authorized dealer, or
call Electro-Voice Customer Ser¬
vice directly at (405) 324-5311,
FAX (405) 324-8981, or write:
Electro-Voice Customer
Service/Repair
10500 West Reno
Oklahoma City, OK 73128 U.S.A.
Electro-Voice Customer
Service/Repair
600 Cecil Street
Buchanan, MI 49107 U.S.A.
Tel: (616) 695-6831
Electro-Voice ® a Mark IV Company
