1. Push the MASTER VOL knob.
The DSP control menu appears.
2. Using the MASTER VOL knob, scroll through the menu items.
3. Push the MASTER VOL knob to select the menu item you want to modify.
The focus moves to the parameters on the right side of the DSP control menu.
4. Using the MASTER VOL knob, scroll through the parameters.
5. Push the MASTER VOL knob to confirm the selected parameter.
The setting is saved. The focus returns to the menu items on the left side of the DSP
control menu.
6. Repeat steps 2 through 5 to modify additional DSP and system settings.
7. Select EXIT to return to the home screen.
5.3.1 Loudspeaker DSP control menu
The loudspeaker DSP control menu selections are available for the EVERSE loudspeakers.
DSP control menu for MIXER mode
VOLUME 0dB (Default)
MUTE, -80dB -
+10dB (1dB)
EXIT
FUNCTION MIXER (Default)
BASIC
MODE MUSIC (Default)
LIVE
SPEECH
CLUB
MAIN LEVEL 0dB (Default)
MUTE, -80dB -
+10dB (1dB)
LOCATION TRIPOD (Default)
KICKBACK
MONITOR
SUB (X-OVER) OFF (Default)
100Hz
120Hz
150Hz
ELX200-12SP
ELX200-18SP
