9 Technical data
1) Full-space measurement
using music DSP preset.
2) Half-space measurement at
1m.
3) Maximum SPL is measured
at 1m using broadband pink
noise at maximum output.
4) Current rating is 1/8 power.
5) Maximum output before
loudspeaker limit indication,
with typical program material
6) Moderate output with
typical program material
7) Powering external devices
via the DC power jack, USB
connection, and/or phantom
power will reduce battery run
time.
EVERSE8-EU 8" 2-way
speaker battery black EU
EVERSE8-US 8" 2-way
speaker battery black US
EVERSE8-W 8" 2-way
speaker battery white
US&EU
Frequency response (-3 dB)
(Hz)
1
60 Hz – 20,000 Hz 60 Hz – 20,000 Hz
Frequency range (-10 dB)
(Hz)
2
50 Hz – 20,000 Hz 50 Hz – 20,000 Hz
Maximum sound pressure
level at a distance of 1 m
(dB)
3
121 dB 121 dB
Coverage angle HxV (°) 100° x 100° 100° x 100°
Amplifier rating (W) 400W 400 W
LF transducer size (in) 8 in 8 in
LF transducer magnet
material
Ferrite Ferrite
HF transducer size (in) 1 in 1 in
HF transducer type Compression driver Compression driver
HF transducer diaphragm
material
Titanium Titanium
HF transducer magnet
material
Neodymium Neodymium
Crossover frequency (kHz) 2.25 kHz 2.25 kHz
Connector type 3.5 mm stereo jack; XLR/TRS
combo jack; charge port; TRS
footswitch; 12V DC power
output
3.5 mm stereo jack; XLR/TRS
combo jack, charge port; TRS
footswitch; 12V DC power
output
Enclosure Polypropylene Polypropylene
Grille material Powder coated steel Powder coated steel
USB charging 1.5 A max., device-dependent 1.5 A max., device-dependent
Color Black White
Dimensions (H x W x D)
(mm)
400 mm x 275 mm x 272 mm 400 mm x 275 mm x 272 mm
Dimensions (H x W x D) (in) 15.75 in x 10.83 in x 10.71 in 15.75 in x 10.83 in x 10.71 in
Weight (kg) 7.60 kg 7.60 kg
Weight (lb) 16.80 lb 16.80 lb
Shipping weight (kg) 11 kg 11 kg
