ARCHIMEDE LCD SERIES - ENG
ELECTROIL
Before reopening of the inverter box to possible change cable or other components, after
functioning, remove voltage and wait at least two minutes, then you can open the box (danger:
contact with electric high voltage parts).
The unit is equipped with all those technical arrangements required to ensure a correct functioning
with a normal installation.
The control system has an entry-filter, also have a current overload protection which guarantees absolute protection
when the Inverter is combined with motors that not exceed the maximum power.
For EMC is good that the power wires of control panel and motor power wires (when the motor are separated from
the inverter) are shielded type (or armoured) with individual conductors of appropriate section (current density <= 5
A/mm2). These cables must be the minimum length necessary. The screen conductor must be connected to the
ground by both sides. On motor use the metal case for connection to the ground of the screen.
To avoid loops that can create mass disturbances radiated (antenna effect), the motor operated by the frequency
converter must be connected on the ground individually, always with a low-impedance using the metallic box of the
machine.
The wires from power supply to frequency converter and wires from frequency converter – motor (if the motor is
separated to the Inverter) must be spaced as much as possible, not to create loops, not make them run parallel
less than 50 cm.
Don’t observe these conditions could cancel completely or partially the effect of the filter integrated.
5.5 Access to the electronic board
In case is necessary to change damaged cables, pressure transducer or to add the float switch contact, you need
to open the Inverter case.
The operations of a component for the inverter must be performed only by experienced personnel
qualified by the manufacturer, using only original spare parts supplied by the manufacturer.
Any action with open box of the Inverter must be made after at least 2 minutes after open line with
appropriate switch or the physical separation from the power supply cable;
In case of failure to one of the cables or the pressure transducer, for the replacement of that should be opened by
unscrewing the inverter cover the N° 12 screws in the back on the heat sink. For the extraction of a cable, unscrew
the three screws that close the cable triangular plate. Remember to always replace the O-ring seal on the cable
under the plate. To connect the cables in the appropriate terminals follow the pattern of connections in the electronic
board below (fig. 14-15-16):
• Single-phase Inverter Power supply cable for IMMP-IMTP: contact 220Vac + GND (J4-1,2,3);
• Three-phase Inverter Power supply cable for ITTP: contact L1, L2, L3 + GND (J7-1,2,3,4);
• Single-phase Motor Power supply cable on IMMP: contact S, T, GND (J3-2, 3, 4);
• Single-phase Motor Power supply cable for IMMP1.1/1.8/2.2: contact MOTOR (J5-1,2)
• Three-phase Motor Power supply cable on IMTP: contact R, S,T, GND (J3-1,2,3,4);
• Three-phase Motor Power supply cable on ITTP: contact U, V,W (J9-1,2,3);
• Pressure transducer with 4-20 mA output: contact +15V, S (J5-1,3);
• Pressure transducer with 4-20 mA output: contact +15V, PS1, PS2 (J11-1,3,4) for IMMP1.1/1.8/2.2;
• Enable: contact ENABLE, 0V (J5-2,5);
• Enable: contact EN, +15V (J11-2,1) for IMMP1.1/1.8/2.2;
• Motor ON output signal: Contact MOTOR ON (J5-4), +15V (J5-5),(J9-1,2 for IMMP1.1/1.8/2.2), command
the fan of the servo-ventilation when the motor is running; Special version, on request: ALARM OUTPUT -
the same contacts provide a +15V (100 mA max.) signal for the Alarm output.
5.6 Connecting the float contact or other NC contact
To connect an enable Normally Closed contact use the poles 2 (Enable) and 5 (common) of J5 (fig. 15,16) or
between EN e +15V(1diJ1) for IMMP1.1/1.8/2.2,fig.14. When the contact open, the Inverter stop the pump; when
the contact close, the pump may re-start at previous working condition.
For the connection of the float switch contact you need to change the three poles cable of the sensor with a four
poles cable, passing on the same central exit of the transducer cable.
The new connections of pressure transducer and float switch contact must be done out of the
Inverter box, protecting them to humidity, water and dust. Do not practice others holes to the Inverter
case to avoid damages or decrease of the protection and insulation grade and interruption in
anticipation of the guarantee.
