4
Section A - Installation Instructions
A
B
D
I
28
3
/
32
"
(71.4 cm)
C
HF
G
2" (5.1 cm)
Min.
1
1
/
2
"
(3.8 cm)
Min.
31"*
(78.7 cm)
3" (7.6 cm)
Max.
Spacer
** Door Open
(see note)
Electrical
Junction Box
4"X 4" (10.2 cm x
10.2 cm) opening to
route armoured
cable.
INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER.
IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors and liquids in
the vicinity of this or any other appliance.
The first step of your installation should be to measure your current cutout dimensions and compare
them to the cutout dimensions chart below. You may find little or no cabinet work will be necessary.
NOTE:
1. Base must be capable of supporting 200 pounds (90.7 kg).
2. Make sure base is level and front of cabinet is square.
Figure 1
All dimensions are in inches (cm).
Do not remove spacers on the side walls and/or on the back of the built-in oven. These
spacers center the oven in the space provided. The oven must be centered to prevent excess heat buildup
that may result in heat damage or fire.
** NOTE: Allow at least 23¼" (59.1 cm)
clearance for door depth when it is open.
NOTE: Dimension G is critical to the
proper installation of the built-in oven. If
the oven decorative moulding does not
butt against the cabinet, or if noise is
heard on convection models, verify
dimension G to assure it is according to
the required dimension.
* Suggested distance from floor is 31" (78.7 cm).
Minimum required distance is 4½" (11.4 cm).
PRODUCT DIMENSIONS
CUTOUT DIMENSIONS AND CABINET WIDTH
MODEL
30" (76.2 cm) Wall Oven
MODEL
30" (76.2 cm) Wall Oven
A
30 (76.2)
Min. F Max.
28½ (72.4) 29 (73.7)
B
29½ (74.9)
G (Min.)
24 (61)
C (Rear wrapper)
28 (71.1)
Min. H Max.
28
1
/
4
(71.8) 28
7
/
8
(73.3)
D
24
1
/
8
(61.3)
I
30 (76.2) Min
