Connection of drain hosesConnection of drain hoses
Insert the drain hose into a drain pipe with a minimum diameter of 40mm, or let
it run into the sink, making sure to avoid bending or crimping it. Use the special
plastic support that comes with the appliance. The free end of the hose must
be at a height lower than1000mm and must not be immersed in water to avoid
the back flow of it.The length of drain pipe must be less than 4m.
Please securely fix the drain hose in either position A or position B
Counter
Drain Pipe(Max. 4m in length)
A
Back of dishwasher
Drain hose
B
Water Inlet
Drain Pipe
Mains Cable
MAX1000 mm
