22
100
80
≥550
560
600
Step 2. Disassemble the adjustable feet to better
match the cabinet.
(If want to keep the feet, the height of the hole
should be more than 610mm.
Step 3. Paste the protective tape.
To get a better drying performance,
the door will open
automatically at the end
of washing cycle. To protect the
cabinet from corroding by the steam, please paste the
protective tape which is provided as accessory.
Built-In Installation
Step 1. Selecting the best location for the dishwasher
The installation position of dishwasher should be near the existing
inlet and drain hoses and power cord.
Illustrations of cabinet dimensions and installation position
of the dishwasher.
(610, if keep the feet)
1. Less than 5 mm between the top of dishwasher and
cabinet and the outer door aligned to cabinet.
2. Make sure there is enough space to fully open the door
(Minimum 500mm).
Dishwasher
Cabinet
Door of
dishwasher
Minimum
space of
500mm
Cabinet
