8. Electrical Components – EFLS617SIW / EFLS517SIW /
EFLS417SIW
Electrical Component Resistance and Specification Table
S. No. Component Resistance Specification
1 Door Lock --
Supply voltage 120 V (95-132 V
60Hz) / 230 V (180-265 V 50-60
Hz), Coil insulation: F
2 Dispenser Solenoid valve Coils resistance @25ºC 990±10% Ω
Cold water temperature-25 ºC
Hot water temperature-60 ºC
Coils room temperature-60 ºC
Nominal Voltage-120 V
Voltage tolerance-(-15% + 10%)
Nominal Frequency-60 Hz
3 Motor --
200 V, 4 A, 330 Hz. (Max.),
RPM (Max.), - 18,600, Insulation
Class-F
4
Heating Element
(Not applicable for 417 series)
13 Ω to 15 Ω 120 V, 60 Hz, 1000 W
5
NTC
(Not applicable for 417 series)
Temp Ω
0 ºC 15771 ± 6.1%
30 ºC 3891 ± 4%
40 ºC 2573 ± 3.4%
50 ºC 1742 ± 2.8%
60 ºC 1204 ± 2.2%
70 ºC 849 ± 2.4%
95 ºC 383 ± 3.6%
--
6 Pressure Sensor --
5 ± 0.25 V DC, 5 mA (Max.)
85 ºC operating temp (Max.)
44 Hz empty drum
7
LED Drum Light
(Not applicable for 417 series)
--
Everlight LED
ELSW-F91C1-OLPGS-C6500
350 mA (Max. LED Current)
Power 1 W
Min. Flux:35 Lumen (55 Typical)
White LED (Cold White) Typical
6500 K
8
Recirculation pump
(Not applicable for 417 series)
and Concentrated Wash Pump
(Not applicable for 417 and 517
series)
31.5 ± 10% Ω @20 ºC
Nominal Voltage-120 V, 60
Hz, Insulation Class F (155),
Working Voltage 95-132 V
9 Drain Pump Winding Resistance-14 ± 10% Ω
Rated-120 VAC / 60 Hz,
Working Voltage-95-132 V AC,
Current and Power with Rotor
locked-1.4 A, 80 W Max.
