23
Component Specifications
S. No. Component Specifications
1 Dispenser Solenoid valve
Cold water temperature-25 ºC
Hot water temperature-60 ºC
Coils room temperature-60 ºC
Nominal voltage-120 V
Voltage tolerance- (-15% + 10%)
Nominal frequency-60 Hz
(Coils resistance @25 ºC 990 ± 10% Ω)
8.8 LED Drum Light
(Not applicable for 417 series)
The high power LED wall Washers are high power LED lights that are used for decorative
lighting and highlight, or wash walls.
Component Specifications
S. No. Component Specifications
1 LED Drum Light
Everlight LED
ELSW-F91C1-OLPGS-C6500
350 mA (Max. LED Current)
Power 1 W
Min. Flux: 35 Lumen (55 Typical)
White LED (Cold White) Typical 6500 K
Electrical Components – EFLS617SIW / EFLS517SIW / EFLS417SIW
