28
Electrical Connection
The oven is designed to be connected to 240 V (50 Hz)
electricity supply.
The oven has an easily accessible terminal block which
is marked as follows.
Letter L Live terminal
Letter N Neutral terminal
Earth
The cable used (of the types: H07 RN-F, H05 RN-F, H05
RR-F, H05 VV-F, H05 V2V2-F (T90), H05 BB-F) must
have a min. cross section of 1.5 mm
2
.
In order to connect it to the oven it is necessary to remove
the hatch at the back of the oven to reach the terminal
block.
For direct connection to the mains supply a two pole
switch with a minimum rating of 13 A and a minimum
distance of 3 mm between its contacts must be fitted
between the supply and appliance.
This switch must not break the yellow/green earth cable
at any point.
The appliance must be earthed
Important
After installation and connecting, the cable must be
placed so that is cannot at any point reach a temperature
more than 50°C above the ambient temperature. Before
the appliance is connected check that:
- the main fuse and the domestic installation can
support the load;
- the power supply is properly earthed;
- the double pole switch used to connect the appliance
to the supply is easily accessible after installation.
