20
5.5 Grounding to Metal Cover
5.6 Water Circuit
WASH PUMP
+ HEATER
Water outlet
Tub
PRESSURE
SENSOR
TURBIDITY
SENSOR
FLOAT SWITCH
Water Tank
resin
SUMP
DRAIN PUMP
Spray arm
Flow Controller
