5.13 Flow Controller (On some Models)
The flow controller controls the water flow towards the dishwasher spray arms.
The flow controller is designed to control the water flow towards the top spray arm only, bottom spray arm only
or towards both spray arms.
Synchronous motor 110/120V AC 60 Hz 3rpmAnti-clockwise rotation
5.14 Pressure Sensor
PRESSURE
MMWCPA
FREQUENCY
TOLERANCE
20
O
C
TOLERANCE 70
O
C
- 44.3 +/- 3mmWC / 1% +/- 5mmWC / 1.7%
75 42.16 +/- 3mmWC / 1% +/- 5mmWC / 1.7%
150 40.0 +/- 6mmWC / 2% +/- 8mmWC / 2.7%
225 37.77 +/- 9mmWC / 3% +/- 11mmWC / 3.7%
