Electrolux W565H - Drive Belt Replacement

24
Drum
8.2Replacementofthebelt
Disconnectthepowertothemachine.
Demounttherearpanel.
Removethebelt(A)andputthenewbeltinposition.
Thebelttensionshouldbeaccordingtothetable,adjustifnecessary.
⑬
A
B, C
A
g.7768A
Remounttherearpanel.
Connectthepowertothemachine.
8.2.1Belttension
Thebelttensionshouldbeaccordingtothetable.
Model
A=Force(N)B=Posttensioning(mm)C=Newbelt(mm)
W565H308
7
W575H308
7
W5105H4098
W5130H53108
W5180H68108
W5240H
75
108
W5300H78108
