Drain
9Drain
9.1Drainvalve
Thewaterpressureinthecoldwaterintakeisusedforclosingthedrainvalve.Thereisahose(1)
connectedbetweenthewaterintakeandthecontrolvalve(2).Whenthecontrolvalveisactivated
itopensandletswaterintothesupplyline(3)whichisconnectedtothedrainvalve.Thewater
pressesuparubbermembrane(4)andaplunger(5)withapressureplate(6)whichclosesthe
valve’srubbermembrane(7).
Whenthecontrolvalveshutsoffwaterpressuretothedrainvalvethesprings(8)pullbackthe
plunger.Thereturnwaterpassesthecontrolvalveandrunsoutintothedrainviathereturnhose(9).
38
1
9
6
8
5
4
2
3
7
g.7757
