Electrolux W565H - Control System Connections

44
Controlpanel
11.1.2Connections
ThecontrolsystemCPUandI/Omoduletype10hasthefollowingconnections:
BoardconnectorFunction
M-COMCommunication,motorcontrol
D-BUS
Databus
D-BUS
Databus
TACHO
Tachometer
COINCoinmeter(coin1,coin2,blocking)priceprogramming
INP1Input1,stopbutton
INP2
Freeprogram(keyswitch)/Input2
RS232Serialcommunication
ENCControlknob(pulses)
USBTYPEBConnectionforsoftware/servicedownload
PINCONNECTOR
Panelsignconnector
LEVELLevelcontrols
DO
Doorout,doorlocksolenoid
OUTPOutput
DOORIN
Doorlockmicroswitches
P-BUS
Powerbus
TEMPTempsensor
44
IN
ENC RS232
INP2
INP1
COIN
TAC HO
D-BUS
D-BUS
M-COM
USB Type B
g.W00284
