Electromed SmartVest - Fitting the SmartVest Wrap

www.smartvest.com
SmartVest SQL Airway Clearance System
8
SmartVest Garments
Fitting the SmartVest Wrap
Steps:
1. Position the SmartVest Wrap around
the patient’s back.
2. Position the arm cutouts beneath underarms.
3. Place the connector-side of the
SmartVest Wrap across chest.
4. Layer the other side of the SmartVest Wrap
over the connector-side using the
Velcro-type closure.
NOTE: The garment should fit “snugly”
but not tightly.
5. Attach the hose to the SmartVest Wrap
(refer to the section on Connecting Hose).
Correct Fit Incorrect Fit
Steps 1 & 2
Step 3
Steps 4 & 5
NOTE: If the front closure opens during treatment, it can be secured by opening
the small strap on the left side of the SmartVest , lacing it through the D ring, and
securing it with the Velcro-type closure.
