5.Since tightening the screws of the build
plate it will be tighter when pulling out the
A4 paper,at that time, you need to calibrate
the height of the Z axis slightly again.
If there is no resistance or only a few
resistance when pulling out the A4 paper,
click to descend the Z axis at the distance
of 0.1mm.
If the paper cannot be pulled out or the
resistance is very high, then you should
click to rise the Z axis at the distance of
0.1mm.If there is some resistance but
you can still pull it out with slight efforts,
then stop adjusting Z axis.
(See picture 4)
6.After the above leveling is completed,
set the current Z axis position as the
initial height if the first layer of printing.
The operation is as follow: Return to the
previous interface and click “Set Z=0”.
At this time, the screen will pop up a
message as shown in the picture. Then
click “Confirm” to complete.
(See picture 5)
（Picture 3）
A4 paper
Please fasten the #1
screw first then the #2 screw.
(Picture 5)
(Picture 4)
No resistance or
a few resistance
when pulling out
the A4 paper.
Unable to pull out the A4 paper.
