Monitoring Live monitoring (mixer output)
A
0 = Live monitoring disabled
1 = Live monitoring enabled
1
PB Mode Playback mode
0 = Pitch, playback slowed down with PB Speed factor
1 = Mixer, playback mixed with peak frequency of the recording
1
PB Speed Playback speed
1 = real-time
2 = half speed
etc.
Example: 10
The recordings are played slowed down 10 times (time expansion and frequency division).
Thus the ultrasonic sounds are audible (e.g. 45 kHz -> 4.5 kHz)
The real-time playback enables the output of the original ultrasonic sounds. This can be
useful for demonstration purpose for example. Pay attention to connect a speaker with
appropriate ultrasound capability.
10
Test Microphone Record the current spectrum and write it to the log file
Setup 4/7
Location / GPS
Position, time and GPS settings
Show Status Displays the current status of GPS reception and information about the current location
GPS Mode Set position determination mode
0 = position determination disabled
1 = position determination enabled
2 = position determination and track recording (GPX) enabled
Example: 0
GPS off for the lowest possible power consumption or because reception is not possible,
such as in caves.
1
Coord.Fmt Coordinates display format to display current location
0 = WGS84 (e.g.. 47.052804 / 8.257801)
1 = CH1903 (e.g.. 662240 / 211632)
0
TZ Set time zone
Deviation to UTC in hours
(The time is set and adapted by GPS reception)
+2
