Elektro-Automatik PS 2000 B Triple Series Instruction Manual

16
EN
Instruction manual
PS 2000 B Triple Series
Date: 11-13-2019
* Related to the nominal value, the accuracy denes the maximum allowed deviation between set value and actual value.
Example: a 42V model has min. 0.2% voltage accuracy, this is 84mV. When setting a voltage of 5V and with an allowed maximum deviation of 84mV,
the resulting actual value could be between 4.92V and 5.08V.
3. Technicalspecications
PS 2342-06B PS 2342-10B PS 2384-03B PS 2384-05B
Mains input
Input voltage 100…240V ±10% 100…240V ±10% 100…240V ±10% 100…240V ±10%
Frequency 45…65 Hz 45…65 Hz 45…65 Hz 45…65 Hz
Fuse MT 4 A MT 6,3 A MT 4 A MT 6,3 A
Power factor > 0.99 > 0.99 > 0.99 > 0.99
Power consumption at output off 24W 24W 24W 24W
Output 1&2 - Voltage
Adjustable range 0...42 V 0...42 V 0...84 V 0...84 V
Stability at mains fluctuation
±10% ∆U
IN
< 0.02% < 0.02% < 0.02% < 0.02%
Stability at 0…100% load < 0.15% < 0.15% < 0.15% < 0.15%
Ripple BWL 20MHz
< 100mV
PP
/ < 4mV
RMS
< 63mV
PP
/ < 5mV
RMS
< 48mV
PP
/ < 4mV
RMS
< 96mV
PP
/ < 24mV
RMS
Accuracy* ≤ 0.2% ≤ 0.2% ≤ 0.2% ≤ 0.2%
Overvoltage protection 0…46.2 V 0…46.2 V 0…92.4 V 0…92.4 V
Regulation time 10-90% load < 2 ms < 2 ms < 2 ms < 2 ms
Softstart max. 200 ms max. 200 ms max. 200 ms max. 200 ms
Output 1 & 2 - Current
Adjustable range 0…6 A 0…10 A 0…3 A 0…5 A
Stability at mains fluctuation
±10% ∆U
IN
< 0.05% < 0.05% < 0.05% < 0.05%
Stability at 0…100% ∆U
OUT
< 0.15% < 0.15% < 0.15% < 0.15%
Ripple
< 25mA
PP
/ < 4mA
RMS
< 13mA
PP
/ < 5mA
RMS
< 6mA
PP
/ < 2mA
RMS
< 9mA
PP
/ < 3mA
RMS
Accuracy* ≤ 0.3% ≤ 0.3% ≤ 0.3% ≤ 0.3%
Output 1 & 2 - Power
Efficiency ≤ 85% ≤ 85% ≤ 85% ≤ 85%
Nominal power P
nom
2x 100W 2x 160W 2x 100W 2x 160W
Output 3
Adjustable range 3…6 V 3…6 V 3…6 V 3…6 V
Power 10 W (max. 12 W) 10 W (max. 12 W) 10 W (max. 12 W) 10 W (max. 12 W)
Stability at mains fluctuation
±10% ∆U
IN
< 0.02% < 0.02% < 0.02% < 0.02%
Stability at 0…100% load < 1.2% < 1.2% < 1.2% < 1.2%
Ripple < 100 mVpp < 100 mVpp < 100 mVpp < 100 mVpp
Nominal current
>2 A @ 5 V
>3.3 A @ 3 V
>2 A @ 5 V
>3.3 A @ 3 V
>2 A @ 5 V
>3.3 A @ 3 V
>2 A @ 5 V
>3.3 A @ 3 V
Miscellaneous
Operation temperature 0….50°C 0….50°C 0….50°C 0….50°C
Storage temperature -20….70°C -20….70°C -20….70°C -20….70°C
Humidity rel. < 80% < 80% < 80% < 80%
Dimensions (WxHxD) 282x82x241 mm 282x82x241 mm 282x82x241 mm 282x82x241 mm
Weight 3,3 kg 3,5 kg 3,3 kg 3,5 kg
Cooling
Safety
EMC standards
Overvoltage class
Protection class
Article number 39200120 39200121 39200125 39200126
Class I
fanless, natural convection
EN 60950
EN 61326, EN 55022 Class B
Class II
