MEDIA INSTALLATION
PLEASE NOTE: not all media options shown are available for sale. Refer to Glen Dimplex Australia for available
options.
GENERAL INSTALLATION NOTE
Lay media in a random arrangement along the entire length of the burner. Refer specific instructions below for each
media type. Media where across the burner should be laid in a criss cross pattern along the full length of the burner. Do
not place media along the burner channel / blocking the burner channel. Do not over stack media at one end.
IMPORTANT
Do not cover or block pilot area.
Incorrect Media Installation
Correct Media Installation
