Slide flue onto connection spigot fully.
Tighten clamp fully.
Wipe excess silicon, visually check connection to ensure
connection is fully sealed.
Air Intake
Connection
Screw or rivet in 3 places to
hold in place.
IMPORTANT- Apply
silicon bead between
inner connection of cowl
and flue pipe to seal
inner flue to cowl. Outer
does not require sealing.
Fit roof sealing method
(Decktite or similar).
Ensure flue is supported and
clipped where required.
Flue Discharge
Connection
To Next Page
