FLUE TERMINATION LOCATION
This section is used to determine where your flue
termination will be located.
• Flue terminations shall not be recessed in walls or
sidings.
• EXTREMELY IMPORTANT: In heavy snow areas take
extra care to prevent blocking flue termination with snow
removal equipment.
• Flue gases exiting flue terminals are very hot and must
not be restricted to assure fireplace combustion is not
affected.
• Do not place, build any obstruction, plant any bushes
or for any reason attempt to conceal the flue termination.
To do so will affect the operation of the fireplace and may
be hazardous.
• This unit must always vent directly to outdoors.
Condensate Disposal
Where possible the condensate drainage pipe should
terminate at a suitable foul water discharge point, eg.
waste drain point washing machine waste point etc.
The HepVO waterless trap should be installed where
access can be maintained.
A P-trap can be used as an option instead of the HepVo
waterless trap.
Do not discharge condensate onto walkways, electrical
connections, earth stakes, copper pipes, waterways,
ponds etc.
POLY PRO GENERAL INSTALLATION
REQUIREMENTS
Refer to specific setups for detailed installation guides.
Poly Pro flue systems meets Flame spread/ Smoke ratings
<25/<50 (per UL-723 ASTM E-84 and ULC-S102)
when used in conjunction with the below noted materials.
• 3m Fire barrier Plenum wrap 5A+
• Unifrax FyreWrap 0.5 Plenum insulation
• Knauf Insulation – Atmosphere Duct wrap with ECOSE
Use soapy water to lubricate gaskets and tubes.
DO NOT USE petroleum based lubricants.
Joint Connections
Verify the gasket is seated evenly inside the groove in
the female end. For PP/Metal pipe with a locking tab,
slide locking band on male pipe section. Insert locking
tab into locking band recess, rotate button away from
locking band clasp, insert pipe sections, push lock band
clamp downward into socket, disengage socket/tab
1/4˝ - 5/8˝ from socket. Screws are not allowed for
joint connection. Never penetrate the wall of PolyPro vent
pipe.
(Exception - a SS screw may be used outside the building
on exterior termination fittings to orient an elbow, etc.)
IMPORTANT: Locking bands are mandatory on all
exhaust vent joints.
