RW80L User Manual
19
4.3 Cash Drawer Connection
1) Make sure the printer's power switch is turned off;
2) Connect the cash drawer cable into the cash drawer interface on the rear side of the printer.
Warning:
Cash drawer interface can only be connected to a voltage of 24V cash drawer device (can’t
connect to the phone line, etc.)
4.4 LED Indication
Function specification of indicated light and beeper.
Name
Status
Specification
POWER
LED
（Green）
ON
The printer works well.
OFF
The printer is powered off.
ERROR
LED
（Red）
Flash
The printer is in an error state
OFF
The printer is in a normal state
PAPER
LED
（Red）
ON
The printer is in paper out state
OFF
The printer is in a normal state
Notes: The printer uses a thermistor to detect the temperature of the print head. If the
temperature of print head is more than 65° C, printer will send a warning. If the temperature
of print head is more than 80° C, printer will stop working until the temperature is less than
60° C.
Description
POWER
LED
ERROR
LED
PAPER
LED
Beeper
Cover Open
ON
ON
ON
“Beep ,Beep--,Beep”
No Paper
ON
ON
ON
“Beep, Beep, Beep”
Cutter Jam
ON
Flash
OFF
”Beep—, Beep—”
