Elenos ET5000 User Manual

21
open
collector
23 Bad audio Signaling output
The pin must be pow-
ered externally.
“Closed to ground”
status --> Active
alarm
open
collector
24 /FLT (reversed polar-
ity)
Signaling output
The pin must be pow-
ered externally.
“Open” Status --> Ac-
tive alarm
The operation can be
affected by the set-
tings of the machine
open
collector
25 Remote Signaling output
The pin must be pow-
ered externally.
“Closed to ground”
status --> Remote
signal active
Product description
2.2.1.4 Full scale values
The nominal full scale corresponds to +4 V, with over stroke of up to more than +4.5
(max +5 V).
ET30000-5
Parameters Full scale Scale factor Resolution
Forward power 30000W 7500W * V Full scale/204
Reflected power 3000W 750W * V
ET25000-5
Parameters Full scale Scale factor Resolution
Forward power 25000W 6250W * V Full scale/204
Reflected power 2500W 625W * V
ET20000-5
Parameters Full scale Scale factor Resolution
Forward power 20000W 5000W * V Full scale/204
Reflected power 2000W 500W * V
ET15000-5
Parameters Full scale Scale factor Resolution
Forward power 15000W 3750W * V Full scale/204
Reflected power 1500W 375W * V
ET10000-5
Parameters Full scale Scale factor Resolution
Forward power 10000W 2500W * V Full scale/204
Reflected power 1000W 250W * V
