Elenos ET5000

47
FM AMPLIFIER MEDIUM POWER | E5000
Overall efficiency (typical from -3dB to Pnom) > = 70%
Power factor > 0.95
Current Consumption @ 230VAC/single phase 31 Amp
Magneto-thermic capacity @ 230VAC/single phase 45 Amp
Conductor size @ 230VAC/single phase 10 sqrt.mm
Conductor size @ 230VAC/single phase 7 AWG
Current Consumption @ 230VAC/three phase 18.5 Amp
Magneto-thermic capacity @ 230VAC/three phase 32 Amp
Conductor size @ 230VAC/three phase 6 sqrt.mm
Conductor size @ 230VAC/three phase 9 AWG
Current Consumption @ 400VAC/three phase 10.5 Amp
Magneto-thermic capacity @ 400VAC/three phase 20 Amp
Conductor size @ 400VAC/three phase 4 sqrt.mm
Conductor size @ 400VAC/three phase 11 AWG
COOLING/NOISE/DATA
Cooling system Forced air-cooling . From 600 to 1200 m3/h
Air temperature increase 17 °C
Acoustic noise < 65 phon
@ transmitter room, 2 m distance of the
front of transmitter
ENVIRONMENT
Temperature range (operating) -5 ÷ +45 °C, 23 ÷ 113 °F
Temperature range (non operating) -20 ÷ +55 °C, -4 ÷ 131 °F
Humidity range (operating) 95% @ 40 °C, 104 °F
Humidity range (non operating) 90% @ 55 °C, 131 °F
Altitude range (operating) <3000 meters / <9840 Feet
Altitude range (non operating) <15000 meters / < 49200 Feet
TELECONTROL & TELEMETRY
Remote control Yes
Remote control, dry contacts Yes
SNMP option Yes (external)
