Page #50 background imageLoading...
Page #50 background image
50
Datasheet
FM AMPLIFIER MEDIUM POWER | E2500
FM AMPLIFIER MEDIUM POWER | E2500
GENERAL DATA
Output Nominal Power 2500 W adjustable
Operating band 87.5 ÷ 108 MHz
RS232/RS485 Yes. Connector DB9 female
Points of measure RF Sample - MPX Monitor
Displayed Parameters More than 50 parameters displayed on a wide
graphic OLED
Adjustments From the frontal panel through OLED/from PC
Number of L-DMOS in amplifier stage 4
RF power stage technology ICEFET & ECOSAVING
Dimensions: Rack units 4U
Dimensions: W - H - D 48.5 - 17.6 - 70 cm
Weight 35 Kg
Number of power supplies 3
Number of cooling fans 6
RF Output connector 7/8”
RF Input connector N
RF PERFORMANCE
Output impedance 50 Ω
Automatic power RF control Stabilizes the output power value on the
set value
Overall output power RF stability +/- 0,1 dB
VSWR 2:1 at full power. Automatic power
reduction beyond 1.7:1. Transmitter is
protected for open and short circuit.
Harmonics < -75 dBc
Out of band emission (spurious) < -80 dBc
AUDIO AND EXCITER PERFORMANCE
Driving power 2W *
INSTALLATION REQUIREMENTS
Power supply 230/400 Threephase-Singlephase
Version 50-60 Hz VAC
Power consumption (typical) 3.5 KW
* Elenos suggests to drive this amplifier with ETG20 Elenos Indium Series
