ELGO Electronic IZ16E-000 Series User Manual

12
6 Technical Data
6.1 Position Indicator IZ16E
6.1.1 Identification
The label is helpful for the identification of the unit. It is located on the housing of the position indicator. It
provides information about the exact type designation (= order reference; see model code, section 7) with the
corresponding item number.
Furthermore, the label contains a unique, traceable device number and production date. These data are always
necessary information if you contact ELGO.
6.1.2 Dimensions
6.1.2.1 Front View / valid for all versions
Front panel cut out:
(W x H) = 93mm x 67mm
Appropriate front panel thickness:
1.0 / 1.5 / 2.0 / 2.5 mm (with mounted seal)
2.5 / 3.0 / 3.5 mm (without seal)
