24
8 Type Designation Magnetic Tape
8.1 Available Variants
Order Code
Description
MB20-25-10-1-R
Magnetic tape in the standard package with cover band and adhesive tape
MB20-25-10-1-R-B
Without tape on the back side/ with enclosed adhesive tape
MB20-25-10-1-R-C
With tape on the back side/ without cover band
MB20-25-10-1-R-D
Without tape on the back side/ without cover tape
Available lengths: 0.5m … 70m
Order example: MB20-25-10-1-R / L=1.5m
ADVERT!
For technical reasons, the measurement cannot be directly carried to
the end of the tape; there should always be a gap of 50mm to adhere
to the cutting edge.
 Tape length = Measuring length + 100 mm 
