ELGO Electronic IZ16E-000 Series User Manual

21
6.3.5
Technical Data Magnetic Tape
Magnetic tape MB20-25-10-1-R
Coding
Incremental, single track
Pole length
2.5mm
Operating temperature
0 °C … +50 °C
Storage temperature
Short term: -10 °C … +60 °C
Medium term: 0 °C …+40 °C
Long term: +18 °C
Relative humidity
max. 95 %, non-condensing
Accuracy at 20°C in mm
+/- (0.025 + 0.02 x L[m])
(L = measuring length in meter)
Thermal expansion
∆L[m] = L[m] x [1/K] x ∆[K]
(L = tape length in meter, ∆ = relative temperature change)
Linear expansion coefficient
  16 x 10
-6
1/K
Bending Radius
min. 150 mm
Available lengths
32m (up to 70m on request)
Weight of the magnetic tape
ca. 62 g/m (inclusive adhesive tape + protective sheet)
Weight of the cover tape
ca. 19 g/m (inclusive adhesive tape + protective sheet)
Influence of external magnetic
fields
External magnetic fields are not allowed to exceed 64 mT (640 Oe; 52
kA/m) at the magnetic tape surface, because it can destroy and damage
the magnetic tape code.
Protection class
IP67
6.3.6
Chemical resistance of the magnetic tape
Chemicals that show little or no impact:
- Formic acid
- Glycerol 93°C
- Linseed oil
- Soybean oil
- cotton oil
- Iso-Octane
- N-Hexane
- Lactic acid
- Formaldehyde 40%
- Petroleum
Chemicals that show weak to moderate effects:
- Acetone
- Petrol
- Acetic acid 20%...30%
- Oleic acid
- Kerosene
- Acetylene
- Steam
- Acetic acid, glacial
acetic acid
- Seawater
- Ammonia
- isopropyl ether
- Stearic acid 70°C
Chemicals that show a strong impact:
- Benzene
- Nitric acid
- Turpentine
- Paint solvents
- Carbon tetrachloride
- Trichlorethylene
- Nitrobenzene
- Hydrochloric acid 37%,
93°C
- Tetrahydrofuran
- Toluene
- Xylene
Type Designation / Variants
Technical Data
