ELGO Electronic IZ16E-000 Series User Manual

35
10.3 Parameter Level
 Adjusting settings
10.3.1 Activate the Parameter Level
Hold it for about 3 seconds / then press each 1x
The parameter level is activated with this key. After about 3 seconds the display shows „P01“for the first
parameter. When the button is actuated again, the corresponding parameter value is displayed, which can then
be changed. With the help of this all parameters are successfully selected.
10.3.2 Election of the Decade
1x pressed
With this key the decade will be advanced by a passage from left to right. The selected, changeable decade is
flashing on the display.
10.3.3 Change Value
1x pressed
With this key the value in the selected decade is always increased by 1 (0…9or 0/1)
10.3.4 Change Sign
With this key the sign can be changed for some parameters. (Negative sign is only possible if the value is not
ZERO)
10.3.5 Leave Parameter Level
Press it for about 3 seconds in the parameter level
All parameters will be retentively stored in the internal flash memory when leaving the parameter level.
Structure and Function Structure and Function

ELGO Electronic IZ16E-000 Series Specifications

General

Brand	ELGO Electronic
Model	IZ16E-000 Series
Category	Measuring Instruments
Language	English
