ELGO Electronic IZ16E-000 Series User Manual

22
7 Type Designation
IZ16E - 000 - 1 - 01.0 - 0 - X
Series / Type:
IZ16E: Position Indicator with external Sensor
Version No.:
000 = Standard
Supply:
1 = integrated battery case with cover (1x Type C / LR14 / Baby)
6 = pluggable screw clamps (2-pole. / 1 mm
2
) for 1.5 V or 3 V
8 = integrated battery case with cover (1 x Type D / LR 20 / Mono / 1.5 V)
(No. 8 only for built-on enclosure  option ‘AG’)
Sensor Cable Length:
(maximum 2 meters)
Cable Options:
0 = fixed cable (Standard)
1 = pluggable round connector (threaded)
Options:
CAP = with integrated battery backup capacitor without actual value loss
24V = for external supply 10...30 VDC
AG = built-on enclosure with mounting holder (IP50)
AG1 = built-on enclosure with mounting holder, sealed up (IP64)
 only for enclosure without RJ45!
