ELGO Electronic IZ16E-000 Series User Manual

27
9.3 Mounting description / Installation of the Indicator
9.3.1 Installation IZ16E-000-x-xx.x-x in the front panel
The mounting of the device in the front panel is achieved by four slide clips (“Snap-In Mounting“).
For this purpose no tools or special tools are needed.
The IZ16E comes with a separate seal. The mounting with seal (optional) increases the protection class for
splash water proof and dust protection. With an installation that is opened on the back, the openings on the side
of the IZ16E must be additionally closed with the arranged stickers (dust protection).
Installation and Initial Start-up
67
+0.6
