ELGO Electronic IZ16E-000 Series User Manual

16
6.1.3
Technical Data IZ16E
Position Indicator IZ16E
LCD-Display
7 decades (digit height 14mm)
With sign, battery status and measurement units
Measuring unit
mm, m, Inch or °
Perspective
12 o’clock
Keyboard
Foil with softkeys
Measuring principle
Magnetic, theoretically absolute
Measurement
linear or rotative
Power supply
1.5 V or 3.0 V (+24V on request)
Power consumption
(with measuring system)
< 1 mA with 1.5V
Battery life
1…3 years (depending on the battery-type)
Operating temperature
0 °C … + 50 °C
Storage temperature
-10 °C … +60 °C
Humidity
max. 80 %, non-condensing
Velocity
max. 4 m/s
Housing
Norm panel housing, ABS plastic, black
Housing dimensions
W x H = 96 x 72 mm
Installation depth
30 mm -> depending on the version, see section 6.1.2
60 mm -> option AG, see section 6.1.2.6
Front panel cut out
W x H = 93 x 67 mm
Protection class front
IP 54 (when installed with sealing)
IP 43 (when installed without sealing)
IP 50 (option AG)
IP 64 (option AG1)
Protection class back
IP 40
IP 50 (option AG)
IP 64 (option AG1)
